XE80CA 液压挖掘机 – 回转装置 Swing Device 310402331
Contact: maipponxcmg@yeah.net
805006391 螺栓 M16×90 Bolt 20
805338296 垫圈16 Washer 27
800551250 回转支承 Swing Bearing 1
805006429 螺栓 M16×80 Bolt 20
805603825 销 12×50 Pin 2
Contact: maipponxcmg@yeah.net
800552603 外圈 Outer Ring 1
800552602 内圈 Inner Ring 1
800552606 油嘴10×1Grease Nipple 2
800552604 钢球 Steel Ball 85
800552607 隔离块 Piece 85
800552605 密封条 Seal 2
800552608 销 10×55 Pin 1
800552609 堵塞 Plug 1
Contact: maipponxcmg@yeah.net
803071776 回转马达 Swing Motor 1
805004813 螺栓 M16×80 Bolt 7
805338296 垫圈16 Washer 7
805638978 销 18×75 Pin 1
