XE75C 液压挖掘机 – 推土先导阀 Pilot Valve 803083389

Contact: maipponxcmg@yeah.net
860202795 弹簧座 Spring Seat 1
860202796 半圆垫片 Washer 2
860202797 O型圈 O-ring 2
860202798 钢丝挡圈 Back-Up Ring 2
860202799 活塞杆 Piston Rod 2
860202800 铜套 Copper Sheathing 2
860202801 U型圈 U-type Washer 2
860202802 挡圈 Back-Up Ring 2
860202803 销 Pin 4
860202804 固定座 Chock 2
860202805 摇摆座 Swing Seat 2
860202806 螺钉 Bolt 2
860202807 调节螺钉 Screw 2
860202808 螺母 Nut 2
860202809 螺母 Nut 2
860202810 操 纵 杆 组 件 Control 1
860202811 防尘套 Dust Seal 1
860202812 自攻螺钉 Screw 1
860202813 手柄帽 Handle Cup 2
860202814 弹簧座 Spring Seat 2
860202815 半圆垫片 Washer 1
860202816 O型圈 O-ring 2
860202817 钢丝挡圈 Back-Up Ring 1
860202818 活塞杆 Piston Rod 1
860202819 铜套 Copper Sheathing 1
860202820 U型圈 U-type Washer 1
