XE470CK 液压挖掘机 – 右先导阀 Right Pilot Valve (803007151)
右先导阀 Right Pilot Valve (803007151)
XE470CK 液压挖掘机零件图册 / Parts Catalog
1520-001
Contact: maipponxcmg@yeah.net
860120199 衬套 Bushing
860120200 盘 Plate 121 86012 0201 密封垫圈 Washer 2
860120202 O形圈 O-Ring
860120203 螺栓 Bolt
860120204 弹簧销 Spring Pin
860120205 衬套 Bushing
860120206 盘 Plate
860120207 阀芯 Spool
860120208 堵头 Plug
860120209 推杆 Push Rod
860120210 密封圈 Seal
860120211 O形圈 O-Ring
860120212 弹簧座 Spring Seat
860120213 垫圈 Washer
860120214 弹簧 Spring
860120215 弹簧 Spring
860120218 螺母 Nut
860120223 防尘罩 Dust Cover
803007151 手柄总成（右） Handle(RH)
