XE370DK 液压挖掘机 – 脚先导阀 Pedal Pilot Valve 803077251
Contact: maipponxcmg@yeah.net
201 860120233 端盖 COVER 2
202 860120234 堵头 PLUG 4
203 860120235 润滑脂盖 GREASE CAP 4
210 860120236 垫片 WASHER 4
212 860120238 O形圈 O-RING 4
214 860120240 推杆 PUSH ROD 4
218 860120243 弹簧座 SPRING SEAT 4
220 860120244 螺钉 SCREW 2
224 860120245 活塞 PISTON 4
225 860120246 轴承钢珠 12
271 860120247 螺栓 BOLT 2
316 860120224 阀体 VALVE BODY 1
335 860120252 弹簧 SPRING 4
337 860120254 弹簧 SPRING 4
412 860120255 轴套 BUSHING 4
413 860120256 凸轮轴 CAM SHAFT 2
420 860120257 凸轮 CAM 2
423 860120258 定位螺钉 SCREW 2
471 860120259 螺钉 SCREW 4
472 860120260 螺母 NUT 4
478 860120225 阀盖 COVER 1
501 860120261 防尘罩 DUST COVER 2
