1 860159235 阀体 HOUSING 1
2 860159236 阀芯总成 PLUNGER 1
3 860159237 阀芯总成 PLUNGER 2
5 860159239 铲斗阀芯总成 PLUNGER 1
6 860159240 PLUNGER 1
7 860159241 O形圈 O-RING 20
8 860159242 挡块 RETAINER 8
9 860159243 螺钉M10×25 BOLT 40
10 860159244 阀盖 COVER 2
11 860159245 阀芯 VALVE 1
12 860159246 阀芯 VALVE 2
13 860159247 动臂1阀芯 VALVE 1
14 860159248 铲斗阀芯 VALVE 1
15 860159249 斗杆2阀芯 VALVE 1
17 860159251 弹簧 SPRING 10
18 860159252 阀套 SPACER 10
19 860159253 弹簧垫圈 1
20 860159254 堵头 PLUG 10

Contact: maipponxcmg@yeah.net

22 860200196 O形圈 O-RING 2
23 860159256 阀盖 COVER 10
24 860159257 主溢流阀 RELIEF 1
25 860201406 O形圈 O-RING 1
26 860201423 O形圈 O-RING 5
27 860159258 O形圈 O-RING 4
28 860159259 O形圈 O-RING 4
29 860201425 O形圈 O-RING 4
30 860159260 阀体 HOUSING 1
31 860159261 PLUNGER 1
32 860159262 PLUNGER 1
33 860159263 阀芯总成 PLUNGER 1
35 860201588 堵头 PLUG 2
36 860200253 O形圈 O-RING 6
37 860159265 回转阀芯 VALVE 1
38 860159266 动臂2阀芯 VALVE 1
39 860159267 阀芯 VALVE 1
40 860159268 斗杆1阀芯 VALVE 1
41 860201424 端盖 PLUG 2

Contact: maipponxcmg@yeah.net

42 860200273 O形圈 O-RING 3
43 860200286 BOLT 8
44 860201404 垫圈 M16 WASHER 8
45 860201401 单向阀 VALVE 1
46 860201400 弹簧 SPRING 1
47 860159269 阀套 SPACER 1
48 860200294 保护盖 PLUG 4
49 860200309 O形圈 O-RING 10
50 860201402 节流阀 VALVE 1
51 860159270 堵头 PLUG 3
52 860201592 挡圈 RETAINER 10
53 860201593 O形圈 O-RING 10
54 860200332 弹簧 SPRING 10
55 860156861 单向阀 VALVE 6
56 860159271 堵头 PLUG 6
57 860159272 阀芯 VALVE 1
58 860159273 堵头 PLUG 4
59 860200325 O形圈 O-RING 8
60 860200326 支撑环 BACK-UP RING 8
61 860159274 O形圈 O-RING 8
62 860159275 端口溢流阀 RELIEF 8
63 860201480 堵头 PLUG 2

Contact: maipponxcmg@yeah.net

64 860200299 O形圈 O-RING 4
65 860159276 堵头 PLUG 1
66 860159277 弹簧 SPRING 1
67 860159278 阀芯 VALVE 1
68 860159279 堵头 PLUG 6
69 860159280 挡圈 BACK-UP RING 6
70 860201491 O形圈 O-RING 6
71 860159281 阀套 SPACER 4
72 860159282 弹簧 SPRING 4
73 860159283 阀芯 VALVE 4
74 860159284 阀芯 VALVE 3
75 860159285 阀芯 VALVE 3
76 860159286 堵头 PLUG 1
77 860159287 弹簧 SPRING 2
78 860159288 阀芯 VALVE 2
79 860159289 法兰板 FLANGE 2
80 860159290 O形圈 O-RING 2
81 860159291 螺钉M10×35 8
82 860159292 堵头 PLUG 1
83 860159293 堵头 PLUG PLUG 1
84 860159294 阀芯 VALVE 1
85 860159295 弹簧 SPRING 2

Contact: maipponxcmg@yeah.net

86 860159296 堵头 2
87 860200313 O形圈 2
88 860159297 阀芯 1
89 860159298 阀盖板 1

Contact: maipponxcmg@yeah.net

90 860159299 螺钉M10×80 4
91 860159300 挡圈 BACK-UP RING 1
92 860159301 O形圈 O-RING 1
93 803416182 O形圈 O-RING 1
94 860159302 螺钉M12×65 8
95 860159303 阀盖板 COVER 2
96 860159304 O形圈 O-RING 2
97 860159305 弹簧 SPRING 2
98 860159306 阀芯 VALVE 2
99 860201511 螺钉M10×45 8
100 860159307 阀盖板 COVER 1
101 860159308 阀盖板 COVER 1
102 860201515 O形圈 O-RING 1
103 860159309 阀盖 COVER 1
104 860200193 堵头 PLUG 3
105 860200314 O形圈 O-RING 4
106 860159310 堵头 PLUG 1
107 860201579 堵头 PLUG 2
