860120224 阀体 CASING 1 D
860120225 阀盖 CASING(DAMPER) 1
860120226 堵头 PLUG 4
860120227 ROH堵头 ROH PLUG 2
860120228 o形圈 O-RING 2
860120229 阀座 SEAT 2
860120230 阀座 SEAT 2
860120231 衬套 BUSH 2
860120232 轴承盖钢珠 STEEL BALL 2
860120233 端盖 COVER 2
860120234 堵头 PLUG 4 D
860120235 润滑脂盖 GREASE CAP 4
860120236 垫片 PACKING 4
860120237 O形圈 O-RING 2
860120238 O形圈 O-RING 4 D
860120239 O形圈 O-RING 4
860120240 推杆 PUSH ROD 4
860120241 垫圈 WASHER 8
860120242 垫圈 WASHER 4
860120243 弹簧座 SPRING SEAT 4
860120244 螺钉 SCREW,HEX.S.H.C. 2
860120245 活塞 PISTON 4
860120246 轴承钢珠 STEEL BALL 12
860120247 螺栓 BOLT 2
860120248 阀芯 SPOOL 4 D
860120249 弹簧座 SPRING SEAT 4
860120250 垫圈 WASHER 4
860120251 弹簧 SPRING 4
860120252 弹簧 SPRING 4
860120253 弹簧 SPRING 4
860120254 弹簧 SPRING 4
860120255 轴套 DU-BUSHING 4
860120256 凸轮轴 CAM SHAFT 2
860120257 凸轮 CAM 2
860120258 定位螺钉 SET SCREW 2
860120259 螺钉 SCREW 4
860120260 螺母 NUT 4
860120261 防尘罩 BELLOWS 2
