XE60D 液压挖掘机 – 主阀 Main Control Valve 803093141
Contact: maipponxcmg@yeah.net
860153802 首联总成 1
860153803 Boom Valve 1
860153804 铲斗总成 1
860153805 斗杆总成 Arm Valve 1
860153806 左行走总成 1
860153807 右行走总成 1
860153808 备用总成 1
860153809 推土总成 1
860153810 回转总成 1
860153811 尾联总成 Rear Valve 1
860153812 连接螺栓 Stud Bolt 4
805238366 螺母 Nut 8
Contact: maipponxcmg@yeah.net
860153813 首联阀块 1
860203689 LS安全节流阀 Relief Valve 1
860153814 弹簧 Spring 1
860153815 弹簧座 Spring Seat 1
860153816 组合密封圈 Seal 1
860153817 阀芯 Spool 1
860203709 节流堵 plug 1
860153818 螺钉 Screw 4
860153819 端盖 Cover 1
860153820 O形圈 O-ring 1
860204465 O形圈 O-ring 1
803384562 O形圈 O-ring 1
860153836 O形圈挡圈 1
860204448 O形圈 O-RING 1
860153837 螺堵 Plug 1
Contact: maipponxcmg@yeah.net
860153838 活塞 Piston 1
860203714 弹簧03 Spring 1
860203713 顶针 Pin 1
860203715 螺母 Nut 1
860153839 阀芯总成 SpoolAssy 1
860153840 弹簧01 Spring 1
860153841 BoomValve 1
860153842 补偿阀总成 1
860203733 螺堵 Plug 4
860153843 安全补油阀 2
860153844 动臂阀芯总成 1
860153845 弹簧座 SpringSeat 2
860153846 弹簧 Spring 2
860127602 螺钉 Screw 6
860153847 端盖 Cover 1
860203725 O形圈 O-ring 1
860204464 O形圈 O-ring 1
803384971 O形圈 O-ring 2
803167982 O形圈 O-ring 1
803380154 O形圈 O-ring 1
860203729 锥阀芯 1
860204476 O形圈 O-ring 2
Contact: maipponxcmg@yeah.net
803384971 O型圈 O-ring 1
860153849 O形圈 1
860153850 端盖 1
Contact: maipponxcmg@yeah.net
860153851 铲斗阀块 1
860153852 补偿阀总成 1
860153853 铲斗阀芯总成 1
860204464 O形圈 O-ring 1
803384971 O形圈 O-ring 2
803167982 O形圈 O-ring 1
803380154 O形圈 O-ring 1
860153845 弹簧座 Spring Seat 2
860153846 弹簧 Spring 2
860204476 O形圈 O-ring 2
860153854 端盖 Cover 2
860127602 螺钉 Screw 4
860153843 安全补油阀 2
Contact: maipponxcmg@yeah.net
860153855 斗杆阀块 Arm Valve 1
860153842 补偿阀总成 1
860153856 斗杆阀芯总成 1
860204464 O形圈 O-ring 1
803384971 O形圈 O-ring 2
803167982 O形圈 O-ring 1
803380154 O形圈 O-ring 2
860153845 弹簧座 Spring Seat 2
860153846 弹簧 Spring 2
860204476 O形圈 O-ring 2
860153854 端盖 Cover 2
860127602 螺钉 Screw 4
860153843 安全补油阀 2
Contact: maipponxcmg@yeah.net
860153857 左行走阀块 Valve Block(L) 1
860153858 节流堵 Plug 1
860153859 O形圈 O-ring 1
860153860 补偿阀总成 1
860203692 O形圈 O-ring 1
860153861 螺堵 Plug 1
860153862 行走阀芯 Valve Block 1
803380154 O形圈 O-ring 1
803384971 O形圈 O-ring 2
803167982 O形圈 O-ring 1
860204464 O形圈 O-ring 1
860153845 弹簧座 Spring Seat 2
860153846 弹簧 Spring 2
860204476 O形圈 O-ring 2
860127602 螺钉 Screw 4
860153854 端盖 Cover 2
860203741 接头 Plug 1
Contact: maipponxcmg@yeah.net
860153863 右行走阀块 Valve Block(R) 1
860153860 补偿阀总成 1
860203692 O形圈 O-ring 2
860153861 螺堵 PLUG 2
860153862 行走阀芯 Valve Block 1
803384971 O形圈 O-ring 2
860204464 O形圈 O-ring 1
803167982 O形圈 O-ring 1
803380154 O形圈 O-ring 1
860203725 O形圈 O-ring 1
860153858 节流堵 Plug 1
860153859 O形圈 O-ring 1
860153845 弹簧座 Spring Seat 2
860153846 弹簧 Spring 2
860127602 螺钉 Screw 4
860153854 端盖 Cover 2
860204476 O形圈 O-ring 2
Contact: maipponxcmg@yeah.net
860153851 铲斗阀块 Bucker Valve 1
860153852 补偿阀总成 1
860204507 螺堵 Plug 2
860153864 备用阀芯总成 1
803384971 O形圈 O-ring 2
860204464 O形圈 O-ring 1
803167982 O形圈 O-ring 1
803380154 O形圈 O-ring 1
860153845 弹簧座 Spring Seat 2
860153846 弹簧 Spring 2
860204476 O形圈 O-ring 2
860153854 端盖 Cover 2
860203705 螺堵 Plug 2
860127602 螺钉 Screw 4
860153843 安全补油阀 2
860153851 铲斗阀块 Bucker Valve 1
860153852 补偿阀总成 1
Contact: maipponxcmg@yeah.net
860203753 阀芯 Spool 1
860153852 补偿阀总成 1
860204464 O形圈 O-ring 1
803167982 O形圈 O-ring 1
803384971 O形圈 O-ring 2
803380154 O形圈 O-ring 1
860153865 推土阀块 Valve Dozer 1
860153843 安全补油阀 2
860153866 推土阀芯总成 1
860204476 O形圈 O-ring 2
860153845 弹簧座 Spring 2
860153846 弹簧 Spring 2
860153854 端盖 Cover 2
860127602 螺钉 Screw 4
Contact: maipponxcmg@yeah.net
860153861 螺堵 Plug 2
860203692 O形圈 O-ring 2
860153842 补偿阀总成 1
860204464 O形圈 O-ring 1
803380154 O形圈 O-ring 1
803167982 O形圈 O-ring 1
803384971 O形圈 O-ring 2
860153867 回转阀块 1
860153868 回转阀芯 Spool 1
860204476 O形圈 O-ring 2
860153845 弹簧座 Spring Seat 2
860153846 弹簧 Spring 2
860153850 端盖 Cover 2
860127602 螺钉 Screw 4
Contact: maipponxcmg@yeah.net
860153704 螺堵 Plug 2
860204511 O形圈 O-ring 2
860204476 O形圈 O-ring 1
860153869 套筒 Sleeve 1
860203762 组合密封圈 Sealing Ring 3
860203763 弹簧 Spring 1
860203764 阀芯 Spool 1
860203761 阀套 Valve Kit 1
860127602 螺钉 Screw 2
860153870 端盖 Cover 1
860204464 O形圈 O-ring 1
803380154 O形圈 O-ring 1
803384971 O形圈 O-ring 2
803167982 O形圈 O-ring 1
860203765 O形圈 O-ring 1
860203766 螺堵 Plug 1
860203733 螺堵 Plug 2
860153871 尾联阀块 Rear Valve 1
Contact: maipponxcmg@yeah.net
860204450 首联总成 1
860204451 铲斗总成 1
860204452 动臂总成 Boom Valve 1
860204453 斗杆总成 Arm Valve 1
860204454 备用总成 1
860204455 左行走总成 1
860204456 右行走总成 1
860204457 推土总成 1
860204458 回转总成 1
860204459 尾联阀块 Rear Valve 1
860204460 铆钉 Rivet 4
860204461 标牌 Label 1
860204424 螺母 Nut 4
860204462 连接螺栓 Stud Bolt 4
Contact: maipponxcmg@yeah.net
860203705 螺堵 Plug 1
860203749 螺堵 Plug 1
860204463 首联阀块 1
860204464 O形圈 O-ring 1
860204465 O形圈 O-ring 3
860203687 O形圈 O-ring 1
860204466 卸荷阀芯 1
860204467 弹簧 Spring 1
860204468 端盖 Cover 1
860204469 LS流量阀 Flow Valve 1
860204470 LS安全阀 Relief Valve 1
860204377 螺堵 Plug 3
860204471 单向节流阀 1
860204472 塑料内堵头 Plug 1
Contact: maipponxcmg@yeah.net
860204473 铲斗阀芯 Spool 1
860204474 溢流阀 Relief Valve 2
860204475 铲斗阀块 Valve Block 1
860204476 O形圈 O-ring 2
860204477 弹簧座 Retainer 2
860204478 弹簧 Spring 2
860204479 端盖 Cover 2
860204480 内六角螺钉 Screw 4
860204481 单向阀 Check Valve 2
860203695 O形圈 O-ring 3
860204464 O形圈 O-ring 1
860203695 O形圈 O-ring 1
860204482 阀芯 Spool 1
860204483 螺堵 Pulg 1
Contact: maipponxcmg@yeah.net
860204480 内六角螺钉 Screw 4
860204484 拉胀堵头 Plug 3
860204485 拉胀堵头 Plug 2
860204486 螺堵 Plug 1
860204487 锥阀芯 1
860204488 弹簧 SPRING 1
860204474 溢流阀 Relief Valve 2
860204489 动臂阀块 Valve Block 1
860204476 O形圈 O-ring 2
860204490 动臂阀芯 Boom Spool 1
860204477 弹簧座 Retainer 2
860204478 弹簧 Spring 2
860204479 端盖 Cover 2
860204481 单向阀 Check Valve 2
860204464 O形圈 O-ring 1
860204483 螺堵 Plug 1
860204491 阀芯 Spool 1
860203695 O形圈 O-ring 2
860204465 O形圈 O-ring 3
Contact: maipponxcmg@yeah.net
860204479 端盖 Cover 2
860204492 螺堵 Plug 1
860204476 O形圈 O-ring 2
860204493 弹簧座 Retainer 1
860204494 阀芯 Spool 1
860204495 阀套 SLEEVE 1
860203725 O形圈 O-ring 1
860204496 活塞 Piston 1
860204497 阀芯 Spool 1
860204498 弹簧 Spring 1
860204499 O形圈挡圈 O-ring 2
860204500 O形圈 O-ring 1
860204501 挡圈 Back-up Ring 2
860203695 O形圈 O-RING 2
860204483 螺堵 Plug 1
860204482 阀芯 Spool 1
860204463 O形圈 O-ring 1
860204465 O形圈 O-ring 3
860204481 单向阀 Check Valve 3
860204480 内六角螺钉 Screw 4
860204478 弹簧 Spring 2
860204477 弹簧座 Retainer 2
Contact: maipponxcmg@yeah.net
860204502 斗杆阀芯 Arm Spool 1
860204474 溢流阀 Relief Valve 2
860204503 斗杆阀块 Valve Block 1
860204504 螺堵 Plug 1
860204504 螺堵 Plug 1
860204505 O形圈 O-ring 1
Contact: maipponxcmg@yeah.net
860204506 溢流阀 Relief Valve 2
860204475 铲斗阀块 Valve Block 1
860204507 螺堵 Plug 2
860204508 备用阀芯 Option Spool 1
860204476 O形圈 O-ring 2
860204477 弹簧座 Retainer 2
860204478 弹簧 Spring 2
860203705 螺堵 Plug 2
860204479 端盖 Cover 2
860204480 内六角螺钉 Screw 4
860204464 O形圈 O-ring 1
860204465 O形圈 O-ring 3
860204481 单向阀 2
860204483 螺堵 Plug 1
860204509 阀芯 Spool 1
860203695 O形圈 O-ring 1
Contact: maipponxcmg@yeah.net
860204510 行走阀芯 Travel Spool 1
860204476 O形圈 O-ring 2
860204477 弹簧座 Retainer 2
860204478 弹簧 Spring 2
860204479 端盖 Cover 2
860204480 内六角螺钉 Screw 4
860204464 O形圈 O-ring 2
860204465 O形圈 O-ring 3
860204511 O形圈 O-ring 2
860204483 螺堵 Plug 1
860204482 阀芯 Spool 1
860203695 O形圈 O-ring 1
860204512 左行走阀块 Valve Block(L) 1
860204513 螺堵 Plug 2
Contact: maipponxcmg@yeah.net
860204514 节流堵 Plug 1
860204515 行走阀芯 Travel Spool 1
860204476 O形圈 O-ring 2
860204477 弹簧座 Retainer 2
860204478 弹簧 Spring 2
860204479 端盖 Cover 2
860204480 内六角螺钉 Screw 4
860204464 O形圈 O-ring 1
860204465 O形圈 O-ring 3
860204462 螺堵 Plug 1
860204482 阀芯 Spool 1
860203695 O形圈 O-ring 1
860204515 右行走阀块 Travel Block® 1
860204511 O形圈 O-ring 2
860204513 螺堵 Plug 2
Contact: maipponxcmg@yeah.net
860204474 溢流阀 Relief Valve 2
860204516 推土阀芯 Dozer Spool 1
860204476 O形圈 O-ring 2
860204477 弹簧座 Retainer 2
860204478 弹簧 Spring 2
860204479 端盖 Cover 2
860204480 内六角螺钉 Screw 4
860204481 单向阀 Check Spool 2
860204464 O形圈 O-ring 1
860204465 O形圈 O-ring 3
860204483 螺堵 Plug 1
860204509 阀芯 Spool 1
860203695 O形圈 O-ring 1
860204475 铲斗阀块 Valve Block 1
Contact: maipponxcmg@yeah.net
860204517 回转阀芯 Spool 1
860204476 O形圈 O-ring 2
860204478 弹簧 Spring 2
860204477 弹簧座 Retainer 2
860204479 端盖 Cover 2
860204480 内六角螺钉 Screw 4
860204464 O形圈 O-ring 1
860204481 单向阀 Check Spool 2
860204465 O形圈 O-ring 3
860204483 螺堵 Plug 1
860204509 阀芯 Spool 1
860203695 O形圈 O-ring 1
860204518 回转阀块 Valve Block 1
