XE55DA 液压挖掘机 – 回转装置 Swing Device 310305497
Contact: maipponxcmg@yeah.net
805006391 螺栓M16×90 Bolt 48
805338285 垫圈16 Washer 24
800556077 Swing Bearing 1
819908813 销12×45-A Pin 2
Contact: maipponxcmg@yeah.net
310406147 销 Pin 1
803099823 回转马达
805046851 螺栓 M16×70 Bolt 7
805338296 垫圈 16 Washer 7
