860120770 滚球轴承 Ball Bearing 1
860120771 滚球轴承 Ball Bearing 1
860120772 销 Pin 1
860120773 螺栓 M14×35L Bolt 10
860120774 密封油 Sealing Oil 1
860120775 多片盘闸 Multi-Plate Disc Brake 3
860120776 摩擦片 Friction Disk 2
860120777 活塞 Piston 1
860120778 D型环 D-Ring 1
860120779 D型环 D-Ring 1
860120780 弹簧 Spring 8
860120781 销 Pin 4
860120782 弹簧 Spring 2
860120783 配流盘 Valve Plate 1
860120784 O形圈 O-Ring 4
860120785 O形圈 O-Ring 1
860120786 螺杆传动1.85×4.8L Screw Drive 2
860120787 运输用塞PT 1 Shipping Plug 2
860120788 运输用塞PT 1/2 Shipping Plug 1
860120789 运输用塞PT 1/4 Shipping Plug 1
860120790 斜角滚珠轴承 Angular Ball Bearing 2
860120791 垫片 T=0.05 Washer 1
860120792 垫片 T=0.1 Washer 1
860120793 垫片 T=0.3 Washer 1
860120794 垫片 T=0.5 Washer 1
860120795 垫片 T=1.0 Washer 1
860120796 轴C Shaft 1

Contact: maipponxcmg@yeah.net

860120797 垫圈 Washer 8
860120798 螺栓 Bolt 8
860120799 止推板 Thrust Plate 4
860120800 轴承内圈 Bearing Inner Race 4
860120801 轴承滚针 Bearing Needle 4
860120802 行星齿轮C Planet Gear 4
860120803 止推板 Thrust Plate 4
860120804 螺栓 Bolt 4
860120805 太阳轮C Sun Gear 1
860120806 弹性挡圈 Circlip 1
860120807 轴B Shaft 1
860120808 止推板 Thrust Plate 3
860120809 轴承内圈 Bearing Inner Race 3
860120810 轴承滚针 Bearing Needle 3
860120811 行星齿轮B Planet Gear 3
860120812 止推板 Thrust Plate 3
860120813 止推板 Thrust Plate 1
860120814 螺钉 Screw 3
860120815 传动齿轮 Transmitting Gear 1
860120816 止推板 T=3.6 Thrust Plate 1
860120817 止推板 T=2.3 Thrust Plate 1
860120818 止推板 T=2.8 Thrust Plate 1
860120819 止推板 T=3 Thrust Plate 1
860120820 止推板 T=3.2 Thrust Plate 1
860120821 端盖 End Cover 1
860120822 螺栓 M10×20L Bolt 16
860120823 螺塞 Plug Screw 3

Contact: maipponxcmg@yeah.net

860120824 O形圈 O-Ring 3
860120825 销 Pin 4
860120836 活塞 Piston 1
860120837 法兰 Flange 1

Contact: maipponxcmg@yeah.net

860120869 柄 Handle 1
860120870 缸体总成 Cylinder 1

Contact: maipponxcmg@yeah.net

860120876 斜盘 Swash Plate 1
860120877 钢珠 Steel Ball 2
860120878 活塞总成 Piston 2
860120879 铭牌 Data Plate 1
860120880 密封垫 Sealing Packing 2
860120881 外壳 Housing 1
860120882 基座总成 Foundation Support 1
