XE150W 液压挖掘机 – 破碎锤管路 Breaker Piping 321001355
Contact: maipponxcmg@yeah.net
803076107 球阀 Valve 2
321000814 管夹 Clamp 4
805338260 垫圈10 Washer 8
805046619 螺栓 M10×60 Bolt 8
321001357 钢管 Pipe 2
803380450 软管总成 Hose 2
321001361 钢管 Pipe 2
Contact: maipponxcmg@yeah.net
805139765 螺栓 M10×35 Bolt 8
805338260 垫圈10 Washer 8
819909188 O型圈 O-ring 2
321001365 钢管 Pipe 1
321001359 钢管 Pipe 1
