910301881 活塞杆 Bar 1
803195138 2
910301885 衬套1 Bushing 2
910305445 导向套 Guide Sleeve 1
910300744 挡圈 Back Up Ring 1
803195139 1
803195140 1
803195141 1
803195142 1
800514019 1
805403133 挡圈75 Back Up Ring 1
803183344 O形圈105×3.1 O-Ring 1
803195144 1
803195145 O形圈94.4×3.1 O-Ring 1
910301893 缸筒 Cylinder 1
910301887 油管组件1 Pipe 1
910305446 缓冲套 Cushion 1
910301637 活塞 Piston 1
803195109 防污环92×100×6 Seal 2
803195110 支承环100×95×9.5 Seal 2
910300397 管夹组件 Clamp 1
805000251 螺栓M14×50 Screw 1
805302898 1
803195147 1
803195112 2

Contact: maipponxcmg@yeah.net

803195113 O形圈49.4×3.1 O-Ring 1
910300402 螺母 Nut 1
805104504 螺钉M8×18 Bolt 1
803195114 2
910301892 衬套2 Bushing 2
805104307 螺钉M14×70 Bolt 12
801103215 油杯M10×1 Oiler Cup 2
910301900 油管组件2 Pipe 1
805104419 螺钉M8×35 Bolt 8
803195143 O形圈21.89×2.62 O-Ring 2
805000048 螺栓M12×25 Screw 2
805302897 2
