801103215 油杯M10×1 Oiler Cup 1
910301938 活塞杆 Bar 1
910301778 挡圈 Back Up Ring 1
803195157 防尘圈 Dust Seal 1
803195158 挡圈 Back Up Ring 1
803195159 密封圈 Seal Ring 1
910305448 导向套 Guide Sleeve 1
803195160 缓冲环 Cushion 1
800514020 滑动轴承 Guide Sleeve 1
805403101 挡圈 Back Up Ring 1
803195161 O形圈 O-Ring 1
803195162 挡圈 Back Up Ring 1
803195163 O形圈 O-Ring 1
910304744 缸筒 Cylinder 1
910305449 缓冲套 Cushion 1
910305517 活塞 Piston 1
803195164 防污环 Seal 2
803417493 支承环 Support Ring 2
803195166 孔密封 Seal Ring 1
803195167 挡圈 Back Up Ring 2
803195168 O形圈 O-Ring 1
805104504 螺钉M8×18 Bolt 1
910301794 螺母 Nut 1
910301869 钢丝挡圈 Back Up Ring 1
910305450 缓冲柱塞 Piston 1
805000048 螺栓M12×25 Screw 2
805302897 2
910301949 接头座 1

Contact: maipponxcmg@yeah.net

910304741 油管组件 Pipe 1
805000251 螺栓M14×50 Screw 1
805302898 1
910301954 卡箍组件 Clamp 1
910304740 衬套2 Bushing 4
805104457 螺钉M10×55 Bolt 4
803195171 O形圈 O-Ring 1
803195169 O形圈 O-Ring 1
805104592 螺钉M10×35 Bolt 4
805104324 螺钉M16×70 Bolt 12
803195318 防尘圈 Dust Seal 4
910305451 阀芯 Spool 1
910301877 弹簧 Spring 1
910303091 垫片 Washer 1
