860153568 活塞杆 Bar 1
860153569 端盖 Cover 1
860153580 缸体 Cylinder 1
860127465 缓冲套d=70 Cushion 1
860127466 活塞 Piston 1
860127467 螺母M50×2 Nut 1
860127468 垫片 Washer 1
860153581 油管组件A Pipe 1
860153582 油管组件B Pipe 1
860153573 卡箍组件 Clamp 1
860127471 压板 Plate 2
860153574 防尘圈 Dust Seal 1
860202111 防尘圈挡圈 Back Up Ring 1
803195141 杆用密封圈 Seal Ring 1
860119353 挡圈 Back Up Ring 1
860153575 缓冲圈 Cushion 1
805139744 螺钉M14×65 Bolt 12
860119355 滑动轴套 Guide Sleeve 1
860202116 1
860119385 O形圈 O-Ring 1
860119386 1
860127521 缓冲环 Cushion 1
860119388 成型导向环 Guide Sleeve 2
860153576 孔用密封圈 Seal Ring 1
860127474 纳污环 Seal 2

Contact: maipponxcmg@yeah.net

805101806 平端螺钉M10×10 Screw 1
860200146 钢球Ф6.5 Steel Ball 1
801102884 油杯M10×1 Oiler Cup 1
805139977 螺钉M8×35 Bolt 8
860119364 O形圈 O-Ring 2
860126942 螺栓M10×40 Screw 2
805300014 2
805048524 螺栓M14×80 Screw 1
805300033 1
860153577 防尘圈 Dust Seal 4
860153578 轴套 C型 Bushing 2
860153579 轴套 Bushing 1
