XE135F 液压挖掘机 – 工作装置管路 Front Piping 310500323
Contact: maipponxcmg@yeah.net
803172510 接头 Joint 4
803172606 软管 Hose 2
310500006 钢管总成III Pipe 1
805139883 螺钉M12×65 Bolt 4
805338261 垫圈 Washer 16
805338281 垫圈 Washer 4
310500327 管夹 Clamp 4
803172605 软管 Hose 2
805139883 螺钉M12×65 Bolt 12
805338281 垫圈 Washer 12
310500355 管夹 Clamp 6
310500325 钢管总成I Pipe 1
310500326 钢管总成II Pipe 1
310500328 钢管总成IV Pipe 1
310500007 钢管 Pipe 10
803371137 接头 Joint 2
